611102234A-0.4D – RF Cable Assembly – N Male Straight to TNC Female Straight 4H for VSW240-FR Cable of Length 0.4m
PART NO:-611102234A-0.4D
- RF CABLE ASSEMBLY
- N-Type to TNC Cable Assembly
- 50Ω LMR240-FR
- Male to Female
Applications:
- In-Building Distributed Antenna Systems (DAS) & Small Cells
- Public Transit, Subways, and Underground Tunnels
- Commercial Wi-Fi Access Point Drops
- Data Centres and Mission-Critical Server Room
- Public Safety & Bi-Directional Amplifier (BDA) Systems
Description
| CONNECTOR SPECIFICATION | |
| RF Series 1 | N |
| Gender | Plug(Male) |
| Orientation1 (body) | Straight |
| Body Plating | Nickel |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| RF Series 2 | TNC |
| Gender | Jack(Female) |
| Orientation1 (body) | Straight |
| Body Plating | Nickel |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Mounting Feature | 4 Hole Flange |
| Frequency | 8GHz |
| Impedance | 50 Ω |
| VSWR | ≤1.2 |
| CABLE SPECIFICATION | |
| Cable Type | LMR240-FR |
| Cable Diameter | 6.096mm |
| Frequency | 8 GHz |
| Impedance | 50 +/- 2 |
| Cable Type | 0.4Meter |
| Temperature Rating | -70°C ~ +85°C |
