11L1203C — RF CONNECTOR – 50 OHMS , SMP MALE , RIGHT ANGLE , SOLDER TYPE , RG405(0.86) CABLE
- RF CONNECTOR: 50Ω
- SMC RP MALE
- STRAIGHT
- SOLDER TYPE
- RG-405 CABLE
Click Here to download the datasheet
Description
The SMP interface is a sub miniature interface in the same scale as MMCX connectors but offers a frequency range of DC to 40 GHz. It is commonly used in miniaturized high frequency coaxial modules and is offered in both push-on and Snap-On mating styles
| CONNECTOR SPECIFICATIONS | |
| Gender | Plug (Male) |
| Orientation | Right Angle |
| Termination Style | Cable – Solder |
| Impedance (Ohms) | 50 |
| Body Finish | Gold |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Contact Termination Style | Solder |
| Insulator Material | PTFE |
| Cable Type | RG405(0.085) |
| Max Frequency (GHz) | DC to 26GHz |
| VSWR(Max) | ≤1.2 |
| Min. Temp. (Celsius) | -65°C |
| Max. Temp. (Celsius) | +165°C |
