VSW260159-CA — RF Cable Assembly – HN Male Right Angle to N Male Right Angle for RG214 Cable of Length 4.6M
PART N/O:-VSW260159-CA
- RF Cable Assembly
- HN type Cable Assembly
- HN type to N type Cable Assembly
- 50Ω RG214
Applications:-
- High-Power RF Systems
- Broadcast and Radar
- Laboratory & Medical Equipment
- Military & Aerospace
Click Here To Download Datasheet
Description
| CONNECTOR SPECIFICATION | |
| RF Series 1 | HN |
| Gender | Plug (Male) |
| Orientation1 (body) | Right Angle |
| Body 1 | Brass, Nickel Plating |
| RF Series 2 | N |
| Gender 2 | Plug (Male) |
| Orientation 2 (body) | Right Angle |
| Body 2 | Brass, Nickel Plating |
| Frequency | DC – 6GHz |
| Impedance | 50 Ω |
| VSWR | ≤1.25 |
| CABLE SPECIFICATION | |
| Cable Type | RG214 |
| Cable Diameter | 10.80±0.20 mm |
| Cable Length | 4.6Meter |
| Max. Operating Frequency | 11GHz |
| Impedance | 50 ±2 ohms |
| Temperature Rating | -40°C ~ +80°C |
