VSW260169-CA – RF Cable Assembly – N Male Straight to TNC Male Straight for RG58 Cable of Length 1.5m
PART NO:-VSW260169-CA
- RF CABLE ASSEMBLY
- N-Type to TNC Cable Assembly
- 50Ω RG58
- Male to Male
Applications:
- Police Cruiser and Emergency Vehicle Fleet Routing
- Land Mobile Radio (LMR) & Two-Way Radio Bench Jumpers
- Low-Frequency Industrial SCADA Enclosures
- Budget-Friendly Test Bench Patching
- Commercial Asset Tracking & Fleet GPS
Description
| CONNECTOR SPECIFICATION | |
| RF Series 1 | N |
| Gender | Plug (Male) |
| Orientation1 (body) | Straight |
| Body Finish | Nickel Plating |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| RF Series 2 | TNC |
| Gender 2 | Plug (Male) |
| Orientation 2 (body) | Straight |
| Body Finish | Nickel Plating |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Frequency | DC-6GHz |
| Impedance | 50Ω |
| VSWR | ≤1.2 |
| CABLE SPECIFICATION | |
| Cable Type | RG58 |
| Cable Diameter | 4.95mm ± 0.20 |
| Max Frequency | 5GHz |
| Weight | 0.040 Kg/m |
| Impedance | 50Ω |
| Cable Length | 1.5Meter |
| Temperature Rating | -40°C ~ +85°C |
