VSW260176-CA – RF Cable Assembly – TNC Male Straight to N Male Right Angle for LMR400-UF Cable of Length 15 Meter
PART NO:-VSW260176-CA
- RF CABLE ASSEMBLY
- N-Type to TNC Cable Assembly
- 50Ω LMR400-UF
- Male to Male
Applications:
- High-Power Mobile Military Masts & Flyaway Kits
- Helicopter & Fixed-Wing Avionics Systems
- Motorized Satellite Tracking & Marine Radar Gimbals
- Heavy-Duty Lab Test Leads & Bench Calibration
- Fleet Transit Vehicles & Mining Equipment
Description
| CONNECTOR SPECIFICATION | |
| RF Series 1 | TNC |
| Gender | Plug(Male) |
| Orientation1 (body) | Straight |
| Body Plating | Nickel |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Beryllium Copper |
| RF Series 2 | N |
| Gender | Plug(Male) |
| Orientation1 (body) | Right Angle |
| Body Plating | Nickel |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Beryllium Copper |
| Frequency | DC to 8GHz |
| Impedance | 50 Ω |
| VSWR | ≤1.2 |
| CABLE SPECIFICATION | |
| Cable Type | LMR400-UF |
| Cable Diameter | 10.29mm |
| Suitable for frequencies | 5.8GHz |
| Length | 15meter |
| Impedance | 50 Ω |
| Weight | 0.131 kg/km |
| Temperature rating | -40 / +85°C |
