VSW- 61110120W-2D – RF Cable Assembly – N Straight Male to N Straight Male for ½” Super Flex Cable of Length 1m
PART NO:-VSW- 61110120W-2D
- RF CABLE ASSEMBLY
- N-Type to N-Type Cable Assembly
- 50Ω ½ Inch Super Flex
- Male to Male
Applications:-
- Cellular Base Station “Jumpers”
- Distributed Antenna Systems (DAS)
- Pantilt Gimbal & Tracking Antennas
- Cabinet & Server Rack Cabling
- Mobile Command Vehicles & Broadcasting Vans
- Precision Lab Testing & Calibration
Description
| CONNECTOR SPECIFICATION | |
| RF Series 1 | N |
| Gender | Plug(Male) |
| Orientation1 (body) | Straight |
| Body Plating | Nickel |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| RF Series 2 | N |
| Gender | Plug(Male) |
| Orientation1 (body) | Straight |
| Body Plating | Nickel |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Frequency | DC-7GHz |
| Impedance | 50 Ω |
| VSWR | ≤1.12 |
| CABLE SPECIFICATION | |
| Cable Type | ½ Inch Super Flex |
| Cable Diameter | 13.30 mm |
| Cut-off Frequency | 12.5 GHz |
| Impedance | 50 Ω |
| Length | 1Meter |
| Operating Temperature | -55 °C ~ +85 °C |
